Five Advantages Of Products
- High stability,7x24 hours no shutdown no outage.
- Front panel IP65 , designed by industrial standard
- Support CAN bus to facilitate customers to build fieldbus network
- adapting to various harsh environments
- WQ brand factory direct sales.
CPU:Cortex A8 Architecture,frequency 1.0GHZ
Memory:512MB DDRⅡ,Flash:256MB NandFlash
CPU:SAMSUNG S3C2416,ARM9 Architecture,frequency 400MHZ
Wide-temperature type, 64K colors or 260K colors
LED backlight:lifetime>25000 hours
Touch screen 4-wire resistance touch screen(driver inside)
4 channel isolated 3-wire RS-232 serial port(COM1,COM2,COM3,COM4),2 channel(COM1、COM2)multiplex as RS-485 bus.
1 channel CAN bus.(optional)(driver inside)
1 channel USB Device interface,support ActiveSync connect to PC to exchange data and debug application.
1 channel USB Host interface,support usual USB device such as mouse, keyboard, U disk ,etc.
1 channel 100M Ethernet interface.
1 channel WIFI module inside.(optional)
1 channel SD/MMC slot.
1 channel 3.5mm audio output interface.
1 channel DC12V~24V,industrial power solution,higher reliability.
【High Configuration】:Windows CE 6.0 R3
【Low Configuration】:Windows CE .NET 5.0
IP65 (front panel)
power:12V DC(12V as recommendation,the range is 12V~24V),600mA
Trepanning size:267.40×198.60 (mm)
industrial control,detection device,instruments and meters,security monitoring,medical apparatus and instruments, intelligent terminals embedded high-end application.
Support CAN bus network deployment.
Flash power-down protection function.
IDE: Visual Studio 2005/2008.net(.net 2.0 Compact)、EVC++、Labview development.
Easy change the user-defined splash screen.
Support display screen rotation (degree: 0/90/180/270)
