Wholesale 7" Resistance Multi-Touch Panel PC Linux Tablet All in One Panel PC

Product model

WLX-070R-AP10

Basic   parameters

CPU: Cortex -A8 architecture,frequency 1.0GHZ
Memory: 512MB DDR3
 Flash:256MB NandFlash

Display   screen

Size:7 inch
Resolution:800×480
Wide-temperature type,64K colors or 260K colors
LED backlight:lifetime > 25000 hours

Touch   screen

4-wire resistance touch screen(driver inside)

Hardware   interface

4 channel isolated 3-wire RS-232 serial port(COM1,COM2,COM3,COM4),2 channel(COM1,COM2)multiplex as RS-485 bus.
1 channel isolated CAN bus.(optional)
1 channel WIFI module inside.(optional)
1 channel USB device interface
2 channel USB Host interface,support usual USB device such as mouse,   keyboard, U disk ,etc.
1 channel 100M Ethernet interface.
1 channel SD/MMC slot.
1 channel 3.5mm audio output interface.
1 channel DC12V~24V,industrial power solution,higher reliability.

OS

Linux

Defend   degree

IP65 (front panel)

Working   environment

power:DC 12~24V ,600mA
working temperature:-10~60ºC
storage temperature:-20~80ºC
working humidity:10~90%RH

Size

shell structure:plastic
panel size:206.00×142.00 (mm)
trepanning size:196.00×132   .00 (mm)

Application   area

industrial control,detection device,instruments and meters,security monitoring,medical apparatus and instruments, intelligent   terminals embedded high-end application.
Support CAN bus network deployment.

Software   support

Flash power-down   protection function.
QT Creator(QT C++)development, easy to use other software flexibly.
  Easy change the user-defined splash   screen.
Support display screen rotation (degree:   0/90/180/270)
